Product Description
U steel framing rollformer wall frame stud rollformer
U steel framing rollformer wall frame stud rollformer is CNC full automatic rollforming line for the C stud U track channel wall frame manufacturing. One U steel framing rollformer wall frame stud rollformer can produce the CU drywall channels by adjusting. For the adjusting methods, there is manual adjusting and automatic adjusting. U steel framing rollformer wall frame stud rollformer full high speed big quantity big speed rollforming machine, it including below parts : De-coiler, levelling system,main roll formng machine , hydraulic station and cutting system. The U steel framing rollformer wall frame stud rollformer is as below:
Above infomation is about the ceiling batten which can be produced by our U steel framing rollformer wall frame stud rollformer.
Below are some specifications of the ceiling batten rollformers:
Model ceiling batten rollformers
Speed 30-40m/min
Thickness 0.42mm
Controlling Panasonic PLC
Manual De-coiler 2 ton de-coiler
Roller station 13 stations
Post cutting 1 set
Roller material Gcr15 finish machining after quenching HRC58-62℃,chromium coating.
Shaft material and diameter 45# steel finish machining,diameter is ￠70mm
Main power 5.5 kw
Hydraulic press 12 Mpa
Hydraulic power 3 kw
Blade material Cr12Mov, quenching HRC 58-62℃
Length tolearance 3m±1.5mm
Voltage Australia standard voltage 415 V
Transmission 1,0 inch single chain
structural Pillar structure
Color Company color
Size Length*Width*Height 6.5m*1,3m*1.2m
U steel framing rollformer wall frame stud rollformer is designed well with high quality material, below are some pictures for your reference:
